Prodigit 34330A Compact High Power DC Electronic Load (30KW,300A,1000V)

  • Manufacturer: PRODIGIT
    Model: 34330A
    • Request a Quotation Request a Quotation
  • Contact
  •  Call for best price

    Hotline: (+84) 867820758

    Phone+84 (24)62923267

  • Quality Engagement
  • Easy change and return
  • Delivery Avaliable
  • Favorable payment

Manufacturer: Prodigit
Made in Taiwan
Model: 34330A
Warrantly: 12 months

Power: 30KW
Current: 0~30A/0~300A
Voltage: 0~1000V
Min.Operation Voltage: 10V@300A
Protections:
  Over Power Protection (OPP): 105%
  Over Current Protection (OCP): 104%
  Over Voltage Protection (OVP): 104%
  Over Temp Protection (OTP): Yes
CC mode:
  Range: 30A/300A
  Resolution: 0.5mA/5mA
  Accuracy: ±0.1%
CR mode:
  Range: 4000~3.333Ω/3.333~0.0336Ω
  Resolution: 5.0005uS/0.056mΩ
  Accuracy: ±0.2%
CV mode:
  Range: 10~1000V
  Resolution: 16mV
  Accuracy: ±0.05%
CP mode:
  Range: 3000W/30000W
  Resolution: 50mW/500mW
  Accuracy: ±0.5%
Measurement mode (Load):
  Voltage: 0 ~ 100V/100~1000V, ±0.025%
  Current : 0 ~ 30A/30~300A, ±0.1%
  Power : 3000W/30000W, ±0.125%
Short circuit current: 300A
Dimension (HxWxD): 1197 x 647 x 766 mm
Weight: 340 kg
Input: 115/230Vac, 50/60Hz
Optional interface: GPIB, RS232, USB, LAN
