Gwinstek PEL-3032E 可编程直流电子负载(500V / 15A / 300W)

  • 制造商: GW INSTEK
    Model: PEL-3032E
    来源: Taiwan
    保障: 12 month
    • 报价要求 报价要求
  • 35,250,000 VND
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




  • 质量承诺
  • 正品保修
  • 送货到家
  • 交易简单化

Model: PEL-3032E
Manual: Gwinstek
Warranty: 12 months
Origin : Taiwan


Power 300W
Range Low High
Voltage2.5~500V;2.5~500V
Current 0~1.5A, 0~15A
Min. Operating Voltage(dc)2.5V-1.5A, 2.5V-15A
Static Mode
Constant Current Mode
Range 0~15A
Setting Range 0~15.3A
Resolution 0.5mA
Accuracy (T *1) ± (0.1% of set +0.1% of F.S)
+Vin/500 kΩ (Full scale of High range)
(T *1) ± (0.1% of set +0.2% of F.S)
+Vin/500 kΩ (Full scale of High range)
Constant Resistance Mode
Range 60S-0.002S(0.01666Ω~500Ω)(300W/15V);
6S-0.0002S(0.1666Ω -5kΩ )(300W/150V)
Setting Range 60S-0.002S(0.01666Ω~500Ω)(300W/15V);
6S-0.0002S(0.1666Ω -5kΩ )(300W/150V)
Resolution(30000 steps) 0.002S(15V) ; 0.0002S(150V)
Accuracy (T *1) ± (0.3% of set + 0.6S) + 0.002mS
Constant Voltage Mode
Range 2.5~500V

Setting Range 0~510V

Resolution 10mV
Accuracy (T *1)± (0.1% of set + 0.1% of F.S)
(Full scale of Low range)
(T *1)± (0.1% of set + 0.1% of F.S)
(Full scale of High range)
Constant Power Mode
Range 3W-30W(6A) 30W-300W(60A)
Setting Range 0W-30.6W 0W-306W
Resolution 1mW 10mW
Accuracy (T *1)±(0.6 % of set + 1.4 % of f.s (Full scale of H range)) + Vin^2/500 kΩ
(Full scale of High range)
General
Function
Trigger In/Out terminal
(BNC)
YES
Current momitor output YES
Accessories
Quick Start Guide
User manual /Programming manual CD
Power cord (Region dependent)
Front terminal washers- Spring washer (M6) x2
GTL-105A Remote sense cables, red x1, blackx1
