Gwinstek GOS-630 模拟示波器(30Mhz,2CH)

Warranty: 12 months
Manufacturer: Gwinstek - Taiwan
Origin: China

CRT

Type 6-inch rectangular type with internal graticule
8 x 10 div (1div=1cm)
Z-Axis Input Input Impedance: Approx. 47kΩ
Sensitivity: Above 5Vp-p
Bandwidth: DC ~ 2MHz

VERTICAL SYSTEM

Sensitivity 5mV/div~5V/div±3%,x5MAG±5%
Bandwidth DC (AC 10Hz) ~ 20MHz(-3dB)
DC (AC 10Hz) ~ 7MHz(-3dB) at x5MAG
Rise Time 17.5ns (50ns at x5MAG)
Input Impedance Approx. 1MΩ
Input Coupling AC, DC, GND
Vertical Mode CH1, CH2, DUAL (ALT/CHOP), ADD, CH2 INV

HORIZONTAL SYSTEM

Sweep Time

0.2μs ~ 0.5s/div±3%
100ns ~ 50ms/div±5% (x 10 MAG)
20ns ~ 50ns/div : uncalibrated

TRIGGER

Trigger Mode AUTO, NORM, TV-V, TV-H
Trigger Source CH1, CH2, ALT, LINE, EXT
Trigger Coupling

AC

Trigger Slope "+" or "-"

X - Y OPERATION

Sensitivity 5mV ~ 5V/div±4%
X-axis Bandwidth DC ~ 500kHz
Phase Error 3° or less from DC ~ 50kHz

OUTPUT SIGNAL

CH1 Signal Output Voltage: approx. 20mV/div into 50Ω
Calibrator Output 1kHz Square wave, 2Vp-p±2%
POWER SOURCE
  AC 115V/230V±15%, 50Hz/60Hz
DIMENSIONS & WEIGHT
  310(W) x 150(H) x 455(D) mm; Approx. 8kg
Details



CRT

Type 6-inch rectangular type with internal graticule
8 x 10 div (1div=1cm)
Z-Axis Input Input Impedance: Approx. 47kΩ
Sensitivity: Above 5Vp-p
Bandwidth: DC ~ 2MHz

VERTICAL SYSTEM

Sensitivity 5mV/div~5V/div±3%,x5MAG±5%
Bandwidth DC (AC 10Hz) ~ 20MHz(-3dB)
DC (AC 10Hz) ~ 7MHz(-3dB) at x5MAG
Rise Time 17.5ns (50ns at x5MAG)
Input Impedance Approx. 1MΩ
Input Coupling AC, DC, GND
Vertical Mode CH1, CH2, DUAL (ALT/CHOP), ADD, CH2 INV

HORIZONTAL SYSTEM

Sweep Time

0.2μs ~ 0.5s/div±3%
100ns ~ 50ms/div±5% (x 10 MAG)
20ns ~ 50ns/div : uncalibrated

TRIGGER

Trigger Mode AUTO, NORM, TV-V, TV-H
Trigger Source CH1, CH2, ALT, LINE, EXT
Trigger Coupling

AC

Trigger Slope "+" or "-"

X - Y OPERATION

Sensitivity 5mV ~ 5V/div±4%
X-axis Bandwidth DC ~ 500kHz
Phase Error 3° or less from DC ~ 50kHz

OUTPUT SIGNAL

CH1 Signal Output Voltage: approx. 20mV/div into 50Ω
Calibrator Output 1kHz Square wave, 2Vp-p±2%
POWER SOURCE
  AC 115V/230V±15%, 50Hz/60Hz
DIMENSIONS & WEIGHT
  310(W) x 150(H) x 455(D) mm; Approx. 8kg
