KEYSIGHT E36311A 可编程直流电源(6 V,5 A和±25 V,1 A,80 W)

  • 制造商: KEYSIGHT
    Model: E36311A
    来源: Malaysia
    保障: 12 month
    • 报价要求 报价要求
  • 27,788,670 VND
  • 价格合理详情请致电

    热线:   (+84) 966520220

    电话:  +84 (24) 62923267




  • 质量承诺
  • 正品保修
  • 送货到家
  • 交易简单化

Manufacturer: KEYSIGHT
Model :
E36311A
Made in Malaysia
Warranty: 12 months



Power output: 80 W

Output Rating:

                       Output 1: 0 to 6 V, 0 to 5 A

                       Output 2: 0 to +25 V, 0 to 1 A

                       Output 3: 0 to -25 V, 0 to 1 A

Ripple & Noise (20 Hz to 20 MHz)

                       Normal Mode Voltage: <350 µVrms/ 2 mV p-p

                       Normal mode current: <2 mA rms, <500 µA rms

Overvoltage protection (OVP): 0.20% +0.1V & 0.20% +0.4 V

Command processing time: < 10 ms

Accuracy 12 months (23 ºC ± 5 ºC)

                         Current 0.1% +10 mA & 0.1% +4 mA

                         Voltage 0.1% +5 mV & 0.05% +10 mV

AC input: AC 100- 230 V, 47- 63 Hz
Interface: USB

includes over voltage, over current, and over temperature protection

Three independent outputs in one instrument saves maintenance cost and bench space

Display: 4.3-inch LCD color show the voltage and current of all three channels at the same time



Included accessories: Power cord, output voltage wire, instruction manual
